Specifications
| Wingspan | 1344mm (52.9in) |
| Length | 1809mm (71.2in) |
| Flying Weight | 8.5kg (18.7 lb)(with 1800cc Aviation kerosene) |
| Turbine Engine | 6～8KG Turbine (required & not included) |
| Cruising speed | 150～200 km/h |
| Flying time | 3～5 mins |
| Wing area | 47.6 dm2 |
| Wing load | 178.6 g/dm2 |
| Main material | 20 times the import of aeromodelling EPO |
| Painting surface | Matte environmental water-borne paint + decal |
| Suitable experience level | □Zero basis □Beginner ■Intermediate □Advanced |
| PNP Assembly difficulty | □☆10mins ■★☆30mins □★★60mins |
| Suitable for ambient temperature | 0℃～40℃ |
| Radio System | 6 channel (required & not included) |
| Control System | MFC-2085 |
| Servos(All 7.4V High voltage) | 40g×2 Metal gear with 60mm lead (left & right Horizontal tail forward) 25g×2 Metal gear with 150mm lead (left & right Aileron forward) 25g×1 Metal gear with 230mm lead (Rudder forward) 12g×2 Metal gear with 480mm lead (with protection function)(Left & right rear cover plate forward) 12g×1 Metal gear with 480mm lead (with protection function)(Front cover plate forward) 12g×1 Metal gear with 320mm lead (with protection function)(Front wheel steering forward) 12g×1 Metal gear with 480mm lead (Front wheel 360 locking forward) 12g×1 Metal gear with 480mm lead (Rear wheel 360 locking reverse) 12g×1 Metal gear with 480mm lead (Rear wheel 360 locking forward) |
| Recommended Battery | 2S,7.4V,3300～5200mAh×2,LiPo with XT60 type plug(required & not included) |
| Ailerons | Yes |
| Flaps | No |
| Elevator(Horizontal tail) | Yes |
| Rudder(Vertical tail) | Yes |
| The smoke system | No |
| LED lights system | Yes |
| Electromagnetic brake system | Yes |
| Reinforced gyro | Selective configuration (not included) |
| Packaging / Size | Packing Box + Outer Box(Card mark)/1456×518×337(mm) |
| CG (Centre of Gravity) | 155～160mm from the leading edge of the Main Wing |
| Landing Gears | All-metal simulation electronic retractable landing gear×3 |
| Battery Charger | LiPo battery charger (required & not included) |
PACKAGE INCLUDES:
- Fuselage×1
- Left Wing×1
- Right Wing×1
- Nose×1
- Cockpit canopy×1
- Vertical Stabilizer×1
- Left Horizontal tail ×1
- Right Horizontal tail ×1
- L/R Auxiliary tank ×1
- L/R wingtip missile ×1
- L/R wingtip missile pylon ×1
- L/R No.1 missile ×1
- L/R No.2 missile ×1
- L/R tail fins ×1
- Main wing carbon tube L=400mm external diameter 10mm×2
- Accessories Bag ×1
- Fuselage antenna ×1
- Pitot×1
- Screw (HA3×14mm)×10 (Nose & Engine)
- Screw (HM3×6mm)×2 (Horizontal tail)
- Screw (HA3×10mm)×8 (Tail nozzle & Vertical)
- Screw (KA3×16mm)×8 (Missile)
- Screw (KA3×20mm)×8 (Missile)
- Screw (KM3×60mm)×8 (Auxiliary tank)
- Screw (HM3×10mm)×8 (Main wing)
- HF-16 V2 Manual×1
- MFC-2085 Manual×1
REQUIRES:
- Turbine 6～8KG Thrust (required & not included)
- 6 channel radio system(radio & receiver) (required & not included)
- 2S, 7.4V, 3300～5200mAh×2 LiPo with XT60 plug (required & not included)
- LiPo battery charger (required & not included)
