Characteristic:

MINI SQ-001 Electric soldering iron is an upgraded version of TS100 internal heat intelligent numerical control soldering iron. Lightweight design, easy to install and use, easy to remove and store, comfortable control handle, high-efficiency heating end, simple control interface. It is a favorite tool for electronic engineers and electronic maintenance enthusiasts.

It can work in DC 12-24V, OLED screen display, key temperature adjustment, external independent power supply. In DC 19V 40W state, 15 seconds temperature rise to 300 ℃.

Controller:

SQ-001 intelligent temperature control between 100-400 degrees, more stable temperature, instantaneous temperature rise, automatic sleep, over temperature alarm and other functions.

Heating end:

*The heating end adopts internal heating core

*Temperature stability range: ± 2%

*External independent power supply: DC 5525 power interface, suitable for DC 12-24v notebook power supply, vehicle power supply and mobile power supply.

*Micro USB interface: set temperature rise curve, user defined function key and firmware upgrade function through parameter file.

*Additional functions: application layer open source design. You can change the internal parameter settings according to your own needs to meet more and more performance needs of different customers.
